[따배씨] 26. User Cluster Role Binding / CKA 시험 문제 학습

이 포스팅은 아래의 유튜브 채널 "따배"를 따라서 학습한 내용입니다.





[관련 이론]

---





[Precondition]

(1) 테스트 환경

(1.1) Rocky Linux Cluster

: 직접 구성

[root@k8s-master ~]# k get nodes -o wide
NAME         STATUS   ROLES           AGE   VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                            KERNEL-VERSION                  CONTAINER-RUNTIME
k8s-master   Ready    control-plane   30d   v1.27.2   192.168.56.30   <none>        Rocky Linux 8.10 (Green Obsidian)   4.18.0-553.33.1.el8_10.x86_64   containerd://1.6.32
k8s-node1    Ready    <none>          30d   v1.27.2   192.168.56.31   <none>        Rocky Linux 8.8 (Green Obsidian)    4.18.0-477.10.1.el8_8.x86_64    containerd://1.6.21
k8s-node2    Ready    <none>          30d   v1.27.2   192.168.56.32   <none>        Rocky Linux 8.8 (Green Obsidian)    4.18.0-477.10.1.el8_8.x86_64    containerd://1.6.21
[root@k8s-master ~]#



(1.2) Ubuntu Cluster

: kodekloud 테스트 환경 활용

controlplane ~ ➜  kubectl get nodes -o wide
NAME           STATUS   ROLES           AGE     VERSION   INTERNAL-IP   EXTERNAL-IP   OS-IMAGE             KERNEL-VERSION   CONTAINER-RUNTIME
controlplane   Ready    control-plane   9m6s    v1.31.0   192.6.94.6    <none>        Ubuntu 22.04.4 LTS   5.4.0-1106-gcp   containerd://1.6.26
node01         Ready    <none>          8m31s   v1.31.0   192.6.94.9    <none>        Ubuntu 22.04.4 LTS   5.4.0-1106-gcp   containerd://1.6.26

https://learn.kodekloud.com/user/courses/udemy-labs-certified-kubernetes-administrator-with-practice-tests



(2) 사전 필요 설정

   : 25번 문제 User role bindng 수행하여 ckauser 및 context 생성

[root@k8s-master ~]# k config get-contexts
CURRENT   NAME                          CLUSTER      AUTHINFO           NAMESPACE
*         ckauser                       kubernetes   ckauser
          k8s                           kubernetes   kubernetes-admin
          kubernetes-admin@kubernetes   kubernetes   kubernetes-admin

[root@k8s-master ~]# k config view
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: DATA+OMITTED
    server: https://192.168.56.30:6443
  name: kubernetes
contexts:
- context:
    cluster: kubernetes
    user: ckauser
  name: ckauser
current-context: ckauser
kind: Config
preferences: {}
users:
- name: ckauser
  user:
    client-certificate-data: DATA+OMITTED
    client-key-data: DATA+OMITTED
[root@k8s-master ~]#

---





[Question]

Create a new ClusterRole named app-clusterrole which only allows to get,watch,list
the following resource types: deployment, service.

- Bind the new ClusterRole app-clusterrole to the new user ckauser.

- User ckauser and ckauser clusters are already configured

- To check the results, run the following command:
  kubectl config use-context ckauser







[Solve]

(1) cluster role 생성

kubectl create clusterrole app-clusterrole --verb=get,list,watch --resource=deployment,service



(2) cluster role binding 생성

kubectl create clusterrolebinding app-clusterrole-binding --clusterrole=app-clusterrole --user=ckauser



(3) context 설정

k config use-context ckauser

---





[사용 커맨드 정리]

kubectl create clusterrole app-clusterrole --verb=get,list,watch --resource=deployment,service

kubectl get clusterrole app-clusterrole

k describe clusterrole app-clusterrole



kubectl create clusterrolebinding app-clusterrole-binding --clusterrole=app-clusterrole --user=ckauser

k get clusterrolebindings.rbac.authorization.k8s.io app-clusterrole-binding

k describe clusterrolebindings.rbac.authorization.k8s.io app-clusterrole-binding



k config use-context ckauser

k config get-contexts
